Features:
- Allows for drilling, roughing thicker materials, trimming and slotting fiber reinforced plastics
- External
Product Specifications
| End Style | Drill Point |
| End Type | Facet Point |
| Point Angle | 135 Degree |
| Size | 5 mm |
| Applicable Material | Composite Materials, Graphite |
| Type | Drilling, Milling & Trimming |
| Length Group | Standard |
| Features: | Suitable for CFRP/GFRP materials. Coarse height tooth profile. Left hand helix for material pushing cuts |
| Coating | ZR |
| Material | Carbide |
| Number of Flutes | 0 |
| Helix Angle (Degrees) | 22 Degree |
| Shank Diameter (mm) | 5 mm |
| Shank Tolerance | 6h |
| Shank Style | HA |
| Overall Length (mm) | 50 mm |
| Flute Length (mm) | 16 mm |
| Flute Direction | Left Hand |
| Application | Finisher |
