Features:
- Increased production rates with higher feed rates
- External
Product Specifications
| End Style | Corner Chamfer |
| End Type | Rough/Finish |
| Size | 5 mm |
| Applicable Material | Steel, Cast Iron, Copper Alloys, Hardened Materials |
| Type | Square End |
| Length Group | Stub Length |
| Features: | Universal design for high performance milling |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 3 |
| Helix Angle (Degrees) | 45 Degree |
| Shank Diameter (mm) | 6 mm |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (mm) | 54 mm |
| Flute Length (mm) | 9 mm |
| Flute Direction | Right Hand |
| Application | Rougher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Mill Diameter (mm):
5mm
Number of Flutes:
3
Length of Cut (mm):
9mm
Material:
Carbide
Finish/Coating:
TIALN
Shank Diameter (mm):
6mm
Application:
Rougher
Overall Length (mm):
54mm
Helix Angle:
45 Degree
Flute Direction:
RH
interval quantity:
1
