Product Specifications
| Chamfer | 1.5-2 P |
| Chamfer Form | E |
| Pitch | 1.5 |
| Size | M 12x1.5 |
| Thread Limit | 6HX |
| Thread Standard | M |
| Coolant Fed | Axial |
| Coating/Finish | TIN |
| Material | HSSE |
| Shank Diameter (mm) | 9 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 100 mm |
| Flute Direction | Right Hand |
