Fullerton Tool 27941 | 12mm Diameter x 12mm Shank x 30mm LOC x 84mm OAL 3 Flute Uncoated Solid Carbide Radius End Mill

$63.24 $61.98
(You save $1.26)
Ships:
From Partner Facility
Brand:
Fullerton Tool
Mill Diameter (mm):
12.00mm
Number of Flutes:
3
Length of Cut (Decimal Inch):
1.1811"
Length of Cut (mm):
30mm
Shank Diameter (Decimal Inch):
0.4724"
Shank Diameter (mm):
12.00mm
Overall Length (Decimal Inch):
3.3071"
Overall Length (mm):
84mm
Material:
Solid Carbide
Finish/Coating:
Uncoated
Single or Double End:
Single
Series:
3833 AlumaMill G3
Ships:
From Partner Facility
interval quantity:
1
SKU:
25002058
UPC:
Weight:
0.50 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Fullerton Tool 27941 | 12mm Diameter x 12mm Shank x 30mm LOC x 84mm OAL 3 Flute Uncoated Solid Carbide Radius End Mill

Features

  • The 3833 AlumaMill G3 is a 3-flute, high performance end mill designed for roughing and finishing aluminum and non-ferrous materials
  • It excels in aggressive plunging and ramping speed environments and was designed for fast material removal and multi-purpose machining
  • Its flute shape and relief form generates superior wall finishes, while its unique wiper geometry produces excellent floor finishes
  • The 3833 AlumMill G3 is stocked uncoated and with FC-5 coating

Product Specifications
Cutting Diameter (Decimal Inch) 0.4724"
Cutting Diameter (mm) 12.00mm
Cutting Flute Length (Decimal Inch) 1.1811"
Cutting Flute Length (mm) 30.00mm
Shank Diameter (Decimal Inch) 0.4724"
Shank Diameter (mm) 12.00mm
Overall Length (Decimal Inch) 3.3071"
Overall Length (mm) 84.00mm
Coating/Finish Uncoated
Metric/Inch Metric
Number of Flutes 3
Helix Angle (Degrees) 37.5
Flute Spiral Direction Right Hand
Direction of Cut Right Hand
Point End Type Corner Radius
End Type Character Designation R
Radius (Decimal Inch) 0.0787"
Radius (mm) 2.00mm
End Type Single End
Coolant Through Non Coolant Through
Weldon Flat No
Length Standard
Length Designator SD
