Fullerton Tool 35603 | 10mm Diameter x 10mm Shank x 32mm LOC x 64mm OAL 4 Flute FC20 Solid Carbide Radius End Mill

$74.68 $73.19
(You save $1.49)
Ships:
From Partner Facility
Brand:
Fullerton Tool
Mill Diameter (mm):
10.00mm
Number of Flutes:
4
Length of Cut (Decimal Inch):
1.2598"
Length of Cut (mm):
32mm
Shank Diameter (Decimal Inch):
0.3937"
Shank Diameter (mm):
10.00mm
Overall Length (Decimal Inch):
2.5197"
Overall Length (mm):
64mm
Material:
Solid Carbide
Finish/Coating:
FC20
Single or Double End:
Single
Series:
3505 Fury Vicor
Ships:
From Partner Facility
interval quantity:
1
SKU:
25002704
UPC:
Weight:
0.30 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Fullerton Tool 35603 | 10mm Diameter x 10mm Shank x 32mm LOC x 64mm OAL 4 Flute FC20 Solid Carbide Radius End Mill

Features

  • The 3505 Fury Vicor is a 4-flute, high performance end mill with chip breakers
  • The chip breakers allow reduced cutting forces and provides excellent chip control when machining stainless steels, super alloys, and titanium
  • It performs exceptionally in high-speed machining and full diameter milling as well as produces excellent surface finishes
  • The 3505 Fury Vicor is stocked with FC-20 coating

Product Specifications
Cutting Diameter (Decimal Inch) 0.3937"
Cutting Diameter (mm) 10.00mm
Cutting Flute Length (Decimal Inch) 1.2598"
Cutting Flute Length (mm) 32.00mm
Shank Diameter (Decimal Inch) 0.3937"
Shank Diameter (mm) 10.00mm
Overall Length (Decimal Inch) 2.5197"
Overall Length (mm) 64.00mm
Coating/Finish FC20
Metric/Inch Metric
Number of Flutes 4
Helix Angle (Degrees) Variable
Flute Spiral Direction Right Hand
Direction of Cut Right Hand
Point End Type Corner Radius
End Type Character Designation R
Radius (Decimal Inch) 0.0098"
Radius (mm) 0.25mm
End Type Single End
Coolant Through Non Coolant Through
Weldon Flat No
Length Standard
Length Designator SD
