Features
- Unique 8" taper design affords highest gripping power
- True double angle, for extreme concentricity
- 16 jaws giving powerful gripping and parallel clamping
- 1/64" collapse per collet
- 0.0005" in TIR precision per DIN 6341
- A unique self releasing system is built into the collet and clamping nut to eliminate cutting tools sticking in collets
Product Specifications
Manufacturer Part Number | 334537N |
Collet Series | TG150 |
Size (Inch) | 1-5/16" |
Overall Length (Decimal Inch) | 3" |
Overall Diameter (Decimal Inch) | 1.875" |
Product Type | Single Angle Collet |
