Harvey Tool 739962 | 0.0620" (1/16) Cutter Diameter x 0.0930" (3/32) LOC x 0.1860" Reach 4 Flute Uncoated Square End Mill

$41.20
Brand:
Harvey Tool
Neck Diameter (Decimal Inch):
0.0605"
Shank Diameter (Inch):
1/8"
Length of Cut (Inch):
3/32"
Length of Cut (Decimal Inch):
0.0930"
Overall Reach (Decimal Inch):
0.1860"
Number of Flutes:
4
Finish/Coating:
Uncoated
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
interval quantity:
1
SKU:
25256621
UPC:
Weight:
0.02 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Features
  • Long length design for deep cavities, up to 10 Inch overall length
  • Stub flutes for maximum rigidity
  • Reduced neck diameter to avoid heeling
  • Length of cut = 1-1/2 x diameter
  • Center cutting
  • Solid carbide
  • CNC ground in the USA

Product Specifications
Manufacturer Part Number739962
Cutter Diameter (Inch)0.0620" (1/16)
Neck Diameter (Inch)0.0605"
Length of Cut (Inch)0.0930" (3/32)
Overall Reach (Inch)0.1860"
Overall Length (Inch)2.5000" (2-1/2)
Shank Diameter (Inch)0.1250" (1/8)
Number of Flutes4
LOC Multiple(1.5x)
Reach Multiple(3x)
CoatingUncoated
ProfileSquare

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Harvey Tool
Neck Diameter (Decimal Inch):
0.0605"
Shank Diameter (Inch):
1/8"
Length of Cut (Inch):
3/32"
Length of Cut (Decimal Inch):
0.0930"
Overall Reach (Decimal Inch):
0.1860"
Number of Flutes:
4
Finish/Coating:
Uncoated
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
interval quantity:
1
