Product Specifications
| Length Of Cut (Decimal Inch) | 0.1900" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 2" |
| End To Center (Decimal Inch) | 0.0000" |
| Radius (Decimal Inch) | 0.0625" |
| Radius (Inch) | 1/16" |
| Angle Per Side | 0 Degree |
| Included Angle | 0 Degree |
| Number of Flutes | 1 |
| Split Length (Decimal Inch) | 0.5000" |
| Split Length (Inch) | 1/2" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (Inch) | 3/16" |
| Metric | No |
| Coating | AlTiN |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Weldon (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Point Shape:
Parallel - Ball
Point Angle:
0 Degree
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Length of Cut (Decimal Inch):
0.1900"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Finish/Coating:
AlTiN
Material:
Solid Carbide
Ships:
From Partner Facility
IsDiscontinued:
