Product Specifications
| Cutter Diameter (Inch) | 1/4" |
| Cutter Diameter (Decimal Inch) | 0.2500" |
| Neck Diameter (Decimal Inch) | 0.1880" |
| Length of Cut (Decimal Inch) | 0.1680" |
| Neck Length (Inch) | 1" |
| Neck Length (Decimal Inch) | 1.0000" |
| Overall Reach (Decimal Inch) | 1.1680" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Radius (Inch) | 1/8" |
| Radius (Decimal Inch) | 0.1250" |
| Wrap Angle | 220 Degree |
| Number of Flutes | 4 |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | Uncoated |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Wrap Angle:
220 Degree
Mill Diameter (Inch):
1/4"
Mill Diameter (Decimal Inch):
0.2500"
Length of Cut (Decimal Inch):
0.1680"
Number of Flutes:
4
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Finish/Coating:
Uncoated
Material:
Carbide
Ships:
From Partner Facility
