Product Specifications
| Length Of Cut (Decimal Inch) | 0.3550" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Tip (Decimal Inch) | 0.0600" |
| Angle Per Side | 15 Degree |
| Included Angle | 30 Degree |
| Number of Flutes | 4 |
| Type | II |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Shank Diameter (Inch) | 1/4" |
| Metric | No |
| Coating | AlTiN |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Single or Double Angle | Single |
| Weldon (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Angle Per Side:
15 Degree
Length Of Cut (Decimal Inch):
0.3550"
Finish/Coating:
AlTiN
Material:
Solid Carbide
Ships:
From Partner Facility
interval quantity:
1
