Product Specifications
| Milling Diameter (Decimal Inch) | 1.0000" |
| Milling Diameter (Inch) | 1" |
| Cutter Width (Decimal Inch) | 0.1870" |
| Cutter Width (Inch) | 3/16" |
| Overall Length (Decimal Inch) | 3.1870" |
| Overall Length (Inch) | 3-3/16" |
| Radial Depth Of Cut (Decimal Inch) | 0.3020" |
| Radius (Decimal Inch) | 0.0937" |
| Radius (Inch) | 3/32" |
| Number of Flutes | 6 |
| Type | II |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Metric | No |
| Coating | AlTiN |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutting Diameter (Inch):
1"
Cutting Diameter (Decimal Inch):
1.0000"
Cutting Width (Inch):
3/16"
Cutting Width (Decimal Inch):
0.1870"
Tooth Configuration:
Straight
Material:
Carbide
Finish/Coating:
AlTiN
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Overall Length (Inch):
3-3/16"
Overall Length (Decimal Inch):
3.1870"
Ships:
From Partner Facility
