Product Specifications
| Pilot Diameter (Decimal Inch) | 0.1540" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Radius (Decimal Inch) | 0.0780" |
| Radius (Inch) | 5/64" |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Shank Diameter (Inch) | 5/16" |
| Metric | No |
| Coating | Uncoated |
| Pilot Flare | 5 |
| Shoulder Flare | 5 |
| Single or Double Angle | Double |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Material:
Solid Carbide
Radius (Inch):
5/64"
Radius (Decimal Inch):
0.0780"
Mill Diameter (Inch):
5/16"
Mill Diameter (Decimal Inch):
0.3125"
Tip Diameter (Decimal Inch):
0.1540"
Number of Flutes:
4
Finish/Coating:
Uncoated
Single or Double End:
Double
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Shank Diameter (Inch):
5/16"
Ships:
From Partner Facility
