Kyocera Precision Tools THC05865 | MCSE336 2.0473-2.0473" Diameter x 0.3386" Maximum Depth of Cut 3 Flute Steel Indexable Chamfering End Mill

$363.04 $301.32
(You save $61.72)
Brand:
Kyocera Precision Tools
Maximum Cutting Diameter (Inch):
2-3/64"
Maximum Cutting Diameter (Decimal Inch):
2.0473"
Maximum Cutting Diameter (mm):
52.00mm
Lead Angle:
45°
Shank Type:
Standard Length
Number of Flutes:
3
Shank Diameter (Decimal Inch):
1.2598"
Shank Diameter (mm):
32.00mm
SKU:
23228951
UPC:
Weight:
1.94 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping

Features:

  • For chamfering, back chamfering, V-Shape slotting, countersinking applications
  • Compatible with (3) SEKW421TN, SEKW422TN, SEKW421FN, SEKW422FN, SEMT421C style inserts

Product Specifications
EDP NumberTHC05865
Maximum Depth of Cut (Decimal Inch)0.3386"
Shank Width (Decimal Inch)0.4724"
Cutting Diameter (Decimal Inch)2.0473 - 2.0473"
Cutting Diameter (mm)52.00 - 52.00mm
Cutting Diameter Maximum (Decimal Inch)2.0473"
Cutting Diameter Maximum (mm)52.00mm
Connection Diameter (Decimal Inch)1.2598"
Connection Diameter (mm)32.00mm
Tool Entering Angle ( Degree)45 Degree
ApplicationBack Chamfering | Chamfering | Countersinking | V-Shape Slotting
HandRight Hand
Insert Holding MethodScrew
MaterialSteel
Number of Flutes3
Number of Inserts3
Shank TypeStandard Length
