Features:
- Low cutting force and reduced chattering for high-efficiency milling
- Great for various milling applications
- New PDL025 grade for machining aluminum
- Compatible with (3) BDMT11T3, BDGT11T3 style inserts
Product Specifications
| EDP Number | THN03509 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937" |
| Cutting Diameter (Decimal Inch) | 0.9843" |
| Cutting Diameter (mm) | 25.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 0.9843" |
| Cutting Diameter Minimum (mm) | 25.00mm |
| Cutting Diameter Maximum (Decimal Inch) | 0.9843" |
| Cutting Diameter Maximum (mm) | 25.00mm |
| Connection Diameter (Decimal Inch) | 0.4921" |
| Connection Diameter (mm) | 12.50mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 0.9055" |
| Contact Surface Diameter Machine Side (mm) | 23.00mm |
| Shank Height (Decimal Inch) | 0.7480" |
| Shank Height (mm) | 19.00mm |
| Tool Entering Angle ( Degree) | 0.8583 Degree |
| Application | Facing | Helical Milling | Plunging | Ramping | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 3 |
| Number of Inserts | 3 |
| Shank Type | Modular Connection |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Series:
MEC;Cutting Diameter (Inch)=63/64"""
Cutting Diameter (Decimal Inch):
0.9843"
Cutting Diameter (mm):
25.00mm
Insert Style:
MEC
Maximum Depth of Cut (Inch):
25/64"
Maximum Depth of Cut (Decimal Inch):
0.3937"
Maximum Depth of Cut (mm):
10mm
