Features:
- Neutral KTKB series, cut-off blade
- Maximum cut-off diameter 35mm
- Compatible with KTKTB-26 tool blocks and TKN1.6, TKN1.6-P, TK1.6, TK1.6-P inserts
Product Specifications
| EDP Number | THP05309 |
| Maximum Depth of Cut (mm) | 6.00mm |
| Maximum Cut-Off Diameter (Decimal Inch) | 1.3780" |
| Maximum Cut-Off Diameter (mm) | 35.00mm |
| Cutting Width (Decimal Inch) | 0.0630" |
| Cutting Width (mm) | 1.60mm |
| Cutting Width Minimum (Decimal Inch) | 0.0630" |
| Cutting Width Minimum (mm) | 1.60mm |
| Cutting Width Maximum (Decimal Inch) | 0.0630" |
| Cutting Width Maximum (mm) | 1.60mm |
| Application | Cut-Off |
| Hand | Neutral |
| Insert Holding Method | Self-Clamp |
| Material | Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Cutting Direction:
Neutral
Blade Style:
KTKB-SS
