Kyocera Precision Tools TJR04002 | KNMX160410L CA5525 3/8" Circle Diameter x 3/16" Thickness CVD Coated Carbide Indexable Turning Insert

$15.58
Brand:
Kyocera Precision Tools
Insert Style:
KNMX
Insert Size:
160410
Material:
Carbide;Inscribed Circle (Inch)=3/8"""
Inscribed Circle (Decimal Inch):
0.3750"
Inscribed Circle (mm):
9.525mm
Thickness (Inch):
3/16"
Thickness (Decimal Inch):
0.1874"
Thickness (mm):
4.76mm
Corner Radius (Decimal Inch):
0.0040"
Corner Radius (mm):
0.10mm
Manufacturer's Grade:
CA5525
SKU:
23236223
Weight:
0.31 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout

Features:

  • Insert for profiling
  • 2 Cutting edges
  • Improved toughness and wear resistance due to tougher carbide substrate and micro columnar structure of coating composition
  • Application: For roughing to interrupted machining of steel

Product Specifications
EDP NumberTJR04002
Inscribed Circle (Inch)3/8"
Inscribed Circle (mm)9.525mm
Corner Radius (Inch)0.004"
Corner Radius (mm)0.10mm
Thickness (Inch)3/16"
Thickness (mm)4.76mm
ApplicationProfiling
Coating ProcessCVD
Cutting RangeMedium Roughing
HandLeft Hand
Insert GradeCA5525
Insert Holding MethodClamp
Insert ShapeParallelogram
Insert Size160410
MaterialCarbide
Number of Cutting Edges2
Primary Workpiece MaterialCarbon/Alloy Steel (P)
Usage ClassificationLight Interruption
