Features:
- Insert for Cut-Off
- 1 Cutting edge
- Improved toughness and stability due to specialized carbide substrate with plastic deformation resistance
- Application: Cut-off, grooving and multi-function cutting of steel
Product Specifications
| Tool Number | TKW15200 |
| Cutting Width (Decimal Inch) | 0.1614" |
| Cutting Width (mm) | 4.10mm |
| Cutting Width Minimum (Decimal Inch) | 0.1614" |
| Cutting Width Minimum (mm) | 4.10mm |
| Cutting Width Maximum (Decimal Inch) | 0.1614" |
| Cutting Width Maximum (mm) | 4.10mm |
| Corner Radius (Inch) | 0.012" |
| Corner Radius (mm) | 0.30mm |
| Application | Cut-Off |
| Coating Process | CVD |
| Cutting Range | Finishing Medium |
| Hand | Neutral |
| Insert Holding Method | Self Clamp |
| Insert Grade | CR9025 |
| Insert Size | 4 |
| Material | Carbide |
| Number of Cutting Edges | 1 |
| Primary Workpiece Material | Steel (P) |
| Usage Classification | Light Interruption |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Material:
Carbide;Insert Style=TKN"
Insert Size:
4
Lead Angle Direction:
Neutral
Cutting Width (Decimal Inch):
0.1614"
Cutting Width (mm):
4.10mm
Manufacturer's Grade:
CR9025
Series:
KTKC
