Kyocera Precision Tools TLC09302 | WCMT06T308 PR1535 0.552" Circle Diameter x 1/32" Radius PVD Coated Carbide Indexable Drill Insert

$10.54
Brand:
Kyocera Precision Tools
Insert Style:
WCMT
Insert Size:
06T308
Material:
Carbide;Manufacturer's Grade=PR1535"
Inscribed Circle (Decimal Inch):
0.3800"
Inscribed Circle (mm):
9.525mm
Thickness (Decimal Inch):
0.1600"
Thickness (mm):
3.97mm
Corner Radius (Decimal Inch):
0.0200"
Corner Radius (mm):
0.80mm
SKU:
23242002
Weight:
0.11 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout

Features:

  • Insert for drilling and coredrilling
  • Stabilized turning operations and long tool life with MEGACOAT NANO coating technology
  • Application: PVD for titanium alloy and precipitation hardened stainless steel

Product Specifications
Tool NumberTLC09302
Insert Included Angle (Degree)80
Inscribed Circle (Inch)3/8"
Inscribed Circle (mm)9.525mm
Corner Radius (Inch)1/32"
Corner Radius (mm)0.80mm
Thickness (Inch)5/32"
Thickness (mm)3.97mm
ApplicationDrilling
Coating ProcessPVD
HandRight Hand
Insert Holding MethodScrew
Insert GradePR1535
Insert Shape80 Degree Trigon
Insert Size06T308
MaterialCarbide
Number of Cutting Edges3
Primary Workpiece MaterialCarbon/Alloy Steel (P) | Tool Steel (P) | Stainless Steel (M) | Cast Iron (K)
Usage Classification
