Features:
- Insert for external grooving
- 3 Cutting edges
- General purpose cermet with superior wear resistance and toughness
- Application: Cutting of steel and stainless steel
Product Specifications
| Tool Number | TSJ89231 |
| Max Depth of Cut (Decimal Inch) | 0.1563" |
| Max Depth of Cut (mm) | 3.97mm |
| Cutting Width (Decimal Inch) | 0.1252" |
| Cutting Width (mm) | 3.18mm |
| Cutting Width Minimum (Decimal Inch) | 0.1252" |
| Cutting Width Minimum (mm) | 3.18mm |
| Cutting Width Maximum (Decimal Inch) | 0.1252" |
| Cutting Width Maximum (mm) | 3.18mm |
| Inscribed Circle (Inch) | 3/8" |
| Inscribed Circle (mm) | 9.525mm |
| Thickness (Inch) | 1/8" |
| Thickness (mm) | 3.18mm |
| Application | External Grooving |
| Chipbreaker | NG |
| Coating Process | Uncoated |
| Cutting Range | Finishing Medium |
| Hand | Neutral |
| Insert Holding Method | Screw |
| Insert Grade | TN60 |
| Insert Size | 32 |
| Material | Cermet |
| Number of Cutting Edges | 3 |
| Primary Workpiece Material | Steel (P) |
| Usage Classification | Continuous |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Insert Style:
TPMC
Insert Size:
32
Material:
Cermet;Cutting Width (Decimal Inch)=0.1252"""
Cutting Width (mm):
3.18mm
Maximum Depth of Cut (Decimal Inch):
0.1563"
Maximum Depth of Cut (mm):
3.97mm
Manufacturer's Grade:
TN60
Finish/Coating:
Uncoated
