Product Specifications
# Manufacturer Number | 0774882 |
Diameter (mm) | 14.10mm |
Shank Size (mm) | 16.00mm |
Flute Length (mm) | 92.00mm |
Overall Length (mm) | 154.00mm |
Drill Point Angle | 135 Degree |
Number of Flute | 2 |
Material | Carbide |
Finish / Coating | REVO-D |
Coolant Through | No |
Cutting Direction | Right |
Flute Type | Conventional Spiral |
Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Flute Type:
Conventional Spiral
Drill Bit Size (Inch):
5/9";Drill Bit Size (Decimal Inch)=0.5551""
Drill Bit Size (mm):
14.10mm
Drill Point Angle:
135 Degree
Overall Length (Inch):
6";Overall Length (Decimal Inch)=6.0630""
Overall Length (mm):
154.00mm
Cutting Direction:
Right
Material:
Carbide
Finish/Coating:
REVO-D
Shank Type:
Endmill Type Shank
Coolant Through:
No
