Face mill with positve/negative geometry which utilises 3 off SEET 09T3AF.. or SEMT 09T3AF.. single-sided inserts, cutting diameter 1.000 to maximum 1.386'' with 45 Degree approach angle and 1.000'' Weldon shank according to DIN 1835B, 3.819'' overall length, through coolant for face milling and chamfering with a maximum depth of cut of .177''.
Product Specifications
| EDP Number | 6789713 |
| Peripheral Effective Cutting Edge Count | 3 |
| Coolant Supply Property | 1 |
| Axial Rake Angle | 20 |
| Radial Rake Angle | -5 |
| Max Rotational Speed | 22000 |
| Connection Diameter (mm) | 25.4 mm |
| Connection Diameter (Inch) | 1" |
| Cutting Diameter (mm) | 25.4 mm |
| Cutting Diameter (Inch) | 1" |
| Max Cutting Diameter (Inch) | 1.386" |
| Overall Length (mm) | |
| Overall Length (Inch) | |
| Usable Length (Inch) | 1.28 mm |
| Country of origin | Czech Republic |
