Lever lock boring bar for holding a 80 Degree rhombus negative insert with an inscribed circle diameter of 9.525 mm, 3.18 mm thick (ISO designation CN.. 0903.. ), right hand 95 Degree side and end cutting with off-set shank, steel with coolant hole, 16 mm diameter x 150 mm long for taper boring and longitudinal boring with and without shoulder.
Product Specifications
| EDP Number | 6761030 |
| Functional Width (mm) | 11 mm |
| Coolant Supply Property | 1 |
| Orthogonal Rake Angle | -5 |
| Inclination Angle | -13.5 |
| Connection Diameter (mm) | 16 mm |
| Connection Diameter (Inch) | 0.63" |
| Shank Height (mm) | 15 mm |
| Shank Width (mm) | 15 mm |
| Minimum Bore Diameter (mm) | 20 mm |
| Functional Length (mm) | 150 mm |
| Direction of Tool | Right |
| Country of origin | Czech Republic |
