Features:
- Accuracy guaranteed to ±.00004
- Free turning Inpro labyrinth seal
- Heavy duty, tri-bearing design
- Full length through hardened spindle
- Body heat treated for additional strength
Product Specifications
| # MFG | 53604 |
| Taper | 4 Morse |
| Accuracy | ± 0.00004 |
| Point Length (Inch) | 1.813" |
| Max Workpiece Weight (lbs) | 2200 lbs. |
| Head Length (Inch) | 2.781" |
| Head Diameter (Inch) | 3.063" |
| Max RPM | 5000 |
| Point Diameter (Inch) | 1.375" |
| Gage Line to Back of Head (Inch) | 0.375" |
| Point Style | Standard Point |
| Series | C4T (Center for Tomorrow) Live Centers |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Riten
Length (Inch):
1"
Length (Decimal Inch):
1.8130"
Length (mm):
46.05mm
Diameter (Inch):
1-3/8"
Diameter (Decimal Inch):
1.3750"
Diameter (mm):
34.93mm
