Features:
- Bar features multifunction design: bore, back bore, thread relief, and back chamfer
- AlTiN+ coating extends tool life
- Elliptically ground neck provides maximum strength
- Made with premium submicron grade carbide
Product Specifications
| Manufacturer Part Number | BC4901500A |
| Minimum Bore Diameter (Decimal Inch) | 0.490" |
| Maximum Depth (Decimal Inch) | 1.500" |
| Cutting Width (Decimal Inch) | 0.110" |
| Radius (Decimal Inch) | 0.010" |
| Coating | AlTiN |
| Material | Solid Carbide |
| Product Type | Back Boring |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Scientific Cutting Tools
Minimum Bore Diameter (Inch):
31/64"
Minimum Bore Diameter (Decimal Inch):
0.4900"
Minimum Bore Diameter (mm):
12.45mm
Maximum Bore Depth (Inch):
1-1/2"
Maximum Bore Depth (Decimal Inch):
1.5000"
Maximum Bore Depth (mm):
38.10mm
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Overall Length (mm):
76.20mm
Material:
Solid Carbide
Finish/Coating:
AlTiN
