Product Specifications
| Manufacturer Part Number | 00000166 |
| Fixing Hole Diameter (Decimal Inch) | 0.114" |
| Fixing Hole Diameter (mm) | 2.90mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.250" |
| Inscribed Circle Diameter (mm) | 6.35mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.354" |
| Cutting Edge Effective Length (mm) | 9.00mm |
| Functional Width (Decimal Inch) | 1.260" |
| Functional Width (mm) | 32.00mm |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (Decimal Inch) | 0.094" |
| Insert Thickness (mm) | 2.38mm |
| Clearance Angle Major (Degree) | 5 Degree |
| Cutting Edge Count | 2 |
| Insert Size And Shape | VB1102 |
| Insert Included Angle (Degree) | 35 Degree |
| Insert Hand | Neutral |
| Material | Carbide |
| Product Type | Turning Insert |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
Seco Tools
Material:
Carbide
Inscribed Circle (Inch):
1/4"
Inscribed Circle (Decimal Inch):
0.2500"
Inscribed Circle (mm):
6.35mm
Thickness (Inch):
3/32"
Thickness (Decimal Inch):
0.0940"
Thickness (mm):
2.38mm
Corner Radius (Inch):
1/32"
Corner Radius (Decimal Inch):
0.0320"
Corner Radius (mm):
0.80mm
interval quantity:
10
