Seco Tools 00077968 | 0.375" Inscribed Circle Diameter x 0.008" Radius x 0.137" Thickness 3 Cutting Edge Carbide Laydown Threading Insert

$34.60 $24.57
(You save $10.03)
Brand:
Seco Tools
Material:
Carbide
Insert Hand:
Right Hand
Inscribed Circle (Inch):
3/8"
Inscribed Circle (Decimal Inch):
0.3750"
Inscribed Circle (mm):
9.53mm
Thickness (Inch):
9/64"
Thickness (Decimal Inch):
0.1370"
Thickness (mm):
3.47mm
interval quantity:
2
SKU:
23275282
UPC:
Weight:
0.01 LBS
Minimum Purchase:
2 units
Shipping:
Calculated at Checkout
Seco Tools 00077968 | 0.375" Inscribed Circle Diameter x 0.008" Radius x 0.137" Thickness 3 Cutting Edge Carbide Laydown Threading Insert

Product Specifications
Manufacturer Part Number00077968
Inscribed Circle Diameter (Decimal Inch)0.375"
Inscribed Circle Diameter (mm)9.53mm
Insert Width (Decimal Inch)0.500"
Insert Width (mm)12.70mm
Corner Radius (Decimal Inch)0.008"
Corner Radius (mm)0.21mm
Insert Thickness (Decimal Inch)0.137"
Insert Thickness (mm)3.47mm
Thread Form TypeISO Metric - Internal Threading
Cutting Edge Count3
Insert HandRight Hand
Tooth Count1
Profile Included Angle (Degree)60 Degree
MaterialCarbide
Product TypeLaydown Threading Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
