Seco Tools 02566082 | 0.625" Inscribed Circle Diameter x 0.039" Radius x 0.187" Thickness 4 Cutting Edge Carbide Milling Insert

$37.70 $26.77
(You save $10.93)
Brand:
Seco Tools
Material:
Carbide
Inscribed Circle (Inch):
5/8"
Inscribed Circle (Decimal Inch):
0.6250"
Inscribed Circle (mm):
15.87mm
Thickness (Inch):
3/16"
Thickness (Decimal Inch):
0.1870"
Thickness (mm):
4.76mm
interval quantity:
10
SKU:
23277969
UPC:
Weight:
0.03 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout
Seco Tools 02566082 | 0.625" Inscribed Circle Diameter x 0.039" Radius x 0.187" Thickness 4 Cutting Edge Carbide Milling Insert

Product Specifications
Manufacturer Part Number02566082
Inscribed Circle Diameter (Decimal Inch)0.625"
Inscribed Circle Diameter (mm)15.87mm
Wiper Edge Length (Decimal Inch)0.059"
Wiper Edge Length (mm)1.50mm
Cutting Edge Effective Length (Decimal Inch)0.457"
Cutting Edge Effective Length (mm)11.60mm
Functional Width (Decimal Inch)0.543"
Functional Width (mm)13.80mm
Corner Radius (Decimal Inch)0.039"
Corner Radius (mm)1.00mm
Insert Thickness (Decimal Inch)0.187"
Insert Thickness (mm)4.76mm
Clearance Angle Major (Degree)20 Degree
Cutting Edge Count4
Cutting Geometry Type TechnicalM18
Pocket Seat Code of The CutterSE..1504
Insert Size And ShapeSEKN1504
Insert HandNeutral
MaterialCarbide
Product TypeMilling Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
