Seco Tools 02749195 | LCMF190202-0200-FTR6 0.008" Corner Radius x 0.112" Thickness 2 Cutting Edge Carbide Multi-Directional Turning Insert

$29.26
Brand:
Seco Tools
Material:
Carbide
Insert Hand:
Right Hand
Thickness (Inch):
7/64"
Thickness (Decimal Inch):
0.1120"
Thickness (mm):
2.85mm
Cutting Width (Inch):
3/38"
Cutting Width (Decimal Inch):
0.0790"
Cutting Width (mm):
2.00mm
Corner Radius (Inch):
1/64"
Corner Radius (Decimal Inch):
0.0080"
Corner Radius (mm):
0.20mm
interval quantity:
1
SKU:
23281027
Weight:
1.23 LBS
Shipping:
Calculated at Checkout
Seco Tools 02749195 | LCMF190202-0200-FTR6 0.008" Corner Radius x 0.112" Thickness 2 Cutting Edge Carbide Multi-Directional Turning Insert

Product Specifications
Manufacturer Part Number02749195
Insert Gauge Length (Decimal Inch)0.728"
Insert Gauge Length (mm)18.50mm
Cutting Width (Decimal Inch)0.079"
Cutting Width (mm)2.00mm
Maximum Cutting Depth Insert (Decimal Inch)0.720"
Maximum Cutting Depth Insert (mm)18.29mm
Corner Radius (Decimal Inch)0.008"
Corner Radius (mm)0.20mm
Insert Thickness (Decimal Inch)0.112"
Insert Thickness (mm)2.85mm
Cutting Edge Count2
Clearance Angle Major (Degree)7 Degree
Insert HandRight Hand
Insert Size And ShapeLC1902
MaterialCarbide
Product TypeMulti-Directional Turning Insert
