Seco Tools 02754903 | VBMT110202-F1 0.250" Inscribed Circle Diameter 0.008" Radius x 0.094" Thickness 2 Cutting Edge Carbide Turning Insert

$24.90 $18.43
(You save $6.47)
Brand:
Seco Tools
Material:
Cermet
Inscribed Circle (Inch):
1/4"
Inscribed Circle (Decimal Inch):
0.2500"
Inscribed Circle (mm):
6.35mm
Thickness (Inch):
3/32"
Thickness (Decimal Inch):
0.0940"
Thickness (mm):
2.38mm
Corner Radius (Inch):
1/64"
Corner Radius (Decimal Inch):
0.0080"
Corner Radius (mm):
0.20mm
interval quantity:
1
SKU:
23281095
UPC:
Weight:
1.23 LBS
Shipping:
Calculated at Checkout
Seco Tools 02754903 | VBMT110202-F1 0.250" Inscribed Circle Diameter 0.008" Radius x 0.094" Thickness 2 Cutting Edge Carbide Turning Insert

Product Specifications
Manufacturer Part Number02754903
Fixing Hole Diameter (Decimal Inch)0.114"
Fixing Hole Diameter (mm)2.90mm
Inscribed Circle Diameter (Decimal Inch)0.250"
Inscribed Circle Diameter (mm)6.35mm
Cutting Edge Effective Length (Decimal Inch)0.413"
Cutting Edge Effective Length (mm)10.50mm
Corner Chamfer Width (mm)0.15mm
Corner Radius (Decimal Inch)0.008"
Corner Radius (mm)0.20mm
Insert Thickness (Decimal Inch)0.094"
Insert Thickness (mm)2.38mm
Clearance Angle Major (Degree)5 Degree
Cutting Edge Count2
Insert Size And ShapeVB1102
Insert Included Angle (Degree)35 Degree
Insert HandNeutral
MaterialCermet
Product TypeTurning Insert
