Seco Tools 03096368 | DN1504 Size x 0.500" Inscribed Circle Diameter x 0.016" Radius x 0.187" Thickness 4 Cutting Edge Carbide Turning Insert

$26.10 $19.31
(You save $6.79)
Brand:
Seco Tools
Material:
Carbide
Inscribed Circle (Inch):
1/2"
Inscribed Circle (Decimal Inch):
0.5000"
Inscribed Circle (mm):
12.70mm
Thickness (Inch):
3/16"
Thickness (Decimal Inch):
0.1870"
Thickness (mm):
4.76mm
Corner Radius (Inch):
1/64"
Corner Radius (Decimal Inch):
0.0160"
Corner Radius (mm):
0.40mm
interval quantity:
10
SKU:
23285877
UPC:
Weight:
0.02 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout
Seco Tools 03096368 | DN1504 Size x 0.500" Inscribed Circle Diameter x 0.016" Radius x 0.187" Thickness 4 Cutting Edge Carbide Turning Insert

Product Specifications
Manufacturer Part Number03096368
Fixing Hole Diameter (Decimal Inch)0.203"
Fixing Hole Diameter (mm)5.15mm
Inscribed Circle Diameter (Decimal Inch)0.500"
Inscribed Circle Diameter (mm)12.70mm
Cutting Edge Effective Length (Decimal Inch)0.595"
Cutting Edge Effective Length (mm)15.10mm
Corner Radius (Decimal Inch)0.016"
Corner Radius (mm)0.40mm
Insert Thickness (Decimal Inch)0.187"
Insert Thickness (mm)4.76mm
Cutting Edge Count4
Insert Size And ShapeDN1504
Insert Included Angle (Degree)55 Degree
Insert HandNeutral
MaterialCarbide
Product TypeTurning Insert
