Product Specifications
| Manufacturer Part Number | 03244821 |
| Minimum Initial Plunge Diameter (mm) | 110.00mm |
| Maximum Initial Plunge Diameter (mm) | 170.00mm |
| Functional Length (mm) | 70.00mm |
| Head Length (mm) | 70.00mm |
| Overall Length (mm) | 154.00mm |
| Functional Height (mm) | 24.95mm |
| Height of Tool Holder Shank (mm) | 25.00mm |
| Shank Width (mm) | 25.00mm |
| Cutting Width (mm) | 6.00mm |
| Maximum Cutting Depth (mm) | 36.00mm |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 96 Degree |
| Cutting Direction | Right Hand |
| Coolant Pressure | Bar |
| Coolant Supply Property | 1 |
| Shank Type | Square shank |
| Product Type | Indexable Grooving Toolholder |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
Seco Tools
Maximum Depth of Cut (Inch):
1-5/12"
Maximum Depth of Cut (Decimal Inch):
1.4173"
Maximum Depth of Cut (mm):
36.00mm
Overall Length (Inch):
6-1/16"
Overall Length (Decimal Inch):
6.0630"
Overall Length (mm):
154.00mm
Shank Width (Inch):
63/64"
Shank Width (Decimal Inch):
0.9800"
Shank Width (mm):
25.00mm
