Product Specifications
| Cutting Diameter (Inch) | 3/32" |
| Shank Diameter (Inch) | 1/4" |
| Length of Cut (Inch) | 3/32" |
| Overall Length (Inch) | 3" |
| Shank Length (Inch) | 2.906" |
| Cut of Direction | Right Hand |
| Flute Type | Spiral |
| Reach (Inch) | 0.198" |
| Helix Angle | 30 Degree |
| Coating | TX |
| Number of Flutes | 2 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Number of Flutes:
2
Length of Cut (Inch):
3/32"
Length of Cut (Decimal Inch):
0.0940"
Length of Cut (mm):
6.35mm
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Overall Length (mm):
76.2mm
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Shank Diameter (mm):
6.35mm
Finish/Coating:
TX
Cutting Direction:
RHC
Helix Angle (Degree):
30 Degree
