Features
- Starrett satin chrome finish - no glare - resists rust on all reading surfaces
- Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
- Quick-reading figures
- Extremely hard and stable one-piece spindle (the heart of our accuracy and long life)
- Micro-lapped measuring face for flatness and squareness
- Quick and easy adjustment
- All graduations are direct reading - no vernier lines to match
- Double figures in red and black on the sleeve and thimble, permitting reading both ways with the spindle moving in either direction
Product Specifications
| Micrometer Type | Mechanical Micrometer Head |
| Range (in) | 0-1" |
| Graduations (in) | .0001" |
| Spindle Material | Carbide |
| Spindle Type | Flat |
| Thimble Type | Plain |
| Accuracy (in) | +/-.00005" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Minimum Measurement (Inch):
0"
Minimum Measurement (Decimal Inch):
0.0000"
Minimum Measurement (mm):
0mm
Maximum Measurement (Inch):
1"
Maximum Measurement (Decimal Inch):
1.0000"
Maximum Measurement (mm):
25.40mm
Spindle Diameter (Inch):
5/16"
Spindle Diameter (Decimal Inch):
0.3120"
Spindle Diameter (mm):
7.92mm
Overall Length (Inch):
5-1/4"
Overall Length (Decimal Inch):
5.2500"
Overall Length (mm):
133.35mm
Graduation (Inch):
0"
Graduation (Decimal Inch):
0.0001"
Spindle Type:
Flat
Material:
Carbide
Finish/Coating:
Satin Chrome
Ships:
From Manufacturer
