Sumitomo 18HMW0V | GCMN3125-RG-AC530U 0.1250" Cutting Width x 0.0625" Radius x 0.1500" Thickness Super ZX Coat Coated Carbide GND Grooving Insert

$28.32 $22.66
(You save $5.66)
Brand:
Sumitomo
Material:
Carbide
Cutting Width (Inch):
1/8"
Cutting Width (Decimal Inch):
0.1250"
Cutting Width (mm):
3.18mm
Maximum Depth of Cut (Inch):
23/32"
Maximum Depth of Cut (Decimal Inch):
0.7090"
Maximum Depth of Cut (mm):
18.00mm
Manufacturer's Grade:
AC530U
Coating:
Super ZX Coat
Insert Hand:
N
Cutting Height (Inch):
5/32"
Cutting Height (Decimal Inch):
0.1500"
Cutting Height (mm):
3.81mm
interval quantity:
1
SKU:
23172497
UPC:
Weight:
0.12 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Sumitomo 18HMW0V | GCMN3125-RG-AC530U 0.1250" Cutting Width x 0.0625" Radius x 0.1500" Thickness Super ZX Coat Coated Carbide GND Grooving Insert

Product Specifications
EDP Number18HMW0V
Product Code - ANSIGCMN3125-RG-AC530U
Manufacturer Grade IdentificationAC530U
SeriesGND
Maximum Depth of Cut (Decimal Inch)0.7090"
Maximum Depth of Cut (mm)18.00mm
Cutting Width (Decimal Inch)0.1250"
Cutting Width (mm)3.18mm
Height (Decimal Inch)0.1500"
Nose Radius (Decimal Inch)0.0625"
Nose Radius (mm)1.59mm
Insert Thickness (Decimal Inch)0.1500"
Insert Thickness (mm)3.81mm
Relief Angle7 Degree
CoatingSuper ZX Coat
Coating ProcessPVD
Standard Designation of the Grade, Main ApplicationP, M, S
Primary Workpiece MaterialP, M, S
Secondary Workpiece MaterialP, M, S
Chip BreakerRG
Insert HandN
Insert MaterialCarbide

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
