Features:
- 3.5X clamping force of standard hydraulic chucks
- 74% thicker bore walls improve rigidity in heavy material removal applications
- Excellent vibration dampening properties enhances surface finish and extends tool life
Product Specifications
| Taper | HSK100A |
| Nose Diameter (Inch) | 2.3" |
| Body Diameter (Inch) | 2.3" |
| Overall Diameter (Inch) | 2.95" |
| Projection (Inch) | 5.12" |
| Nose Length (Inch) | 3.98" |
| Bore Depth (Inch) | 2.24" |
| Overall Length (Inch) | 5.91" |
