Features:
- Rolled threads maintain material grain structure improving thread strength up to 20%
- Each MegaFORCE Retention knob is magnetic particle tested to ensure material integrity and physical soundness
- Tested at 2.5X the pulling forces of the drawbar
Product Specifications
| Taper Size | BT30 |
| Degree | 45° |
| Overall Diameter (Inch) | 0.669" |
| Head Diameter (Inch) | 0.433" |
| Neck Diameter (Inch) | 0.276" |
| Body Diameter (Inch) | 0.669" |
| Flange to Top Length (Inch) | 0.906" |
| Flange to Center of head Length (Inch) | 0.709" |
| Thread | M12-1.75 |
