Features:
- H5 bore tolerance for improved concentricity and tool life
- Taper ground to AT3 specification for maximum spindle contact
- Balanced to 15,000 RPM at G6.3
Product Specifications
| Taper | SCAT50 |
| Body Diameter (inch) | 2.75" |
| Body Width (inch) | 2.75" |
| Overall Diameter (Inch) | 3.875" |
| Projection (Inch) | 6" |
| Nose Diameter (Inch) | 3.75" |
| Overall Length (inch) | 10" |
| Material | 8620 Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
CAT50
Body Diameter (Decimal Inch):
2.7500"
Nose Diameter (Decimal Inch):
3.7500"
Overall Length (Decimal Inch):
10.0000"
Overall Diameter (Decimal Inch):
3.8750"
Bore Size (Inch):
2"
Bore Size (Decimal Inch):
2.0000"
interval quantity:
1
