Lever-lock boring bar, for negative 55 degree rhombic insert.
Product Specifications
| # MFG | 6806094 |
| Connection Diameter Machine Side (mm) | 50mm |
| Functional Length (mm) | 375mm |
| Functional Width (mm) | 35mm |
| Head Length (mm) | 65mm |
| Minimum Bore Diameter (mm) | 60mm |
| Shank Height (mm) | 47mm |
| Shank Width (mm) | 47.5mm |
| Body Material | Steel |
| Application | For 55 Degree Rhombic Insert |
| Tool Type | Internal Indexable-Turn Tool |
| Rake Angle Axial (Degree) | 6 Degree |
| Rake Angle Radial (Degree) | -8 Degree |
