Product Specifications
| Manufacturer Part Number | 0451JCN |
| Diameter (Inch) | 14/79" |
| Diameter (Decimal Inch) | 0.1772" |
| Diameter (mm) | 4.50mm |
| Shank Diameter (Inch) | 14/79" |
| Shank Diameter (Decimal Inch) | 0.1772" |
| Shank Diameter (mm) | 4.50mm |
| Flute Length (Inch) | 17/18" |
| Flute Length (Decimal Inch) | 0.9449" |
| Flute Length (mm) | 24.00mm |
| Overall Length (Inch) | 2-21/31" |
| Overall Length (Decimal Inch) | 2.6772" |
| Overall Length (mm) | 68.00mm |
| Point Length (Decimal Inch) | 0.0511" |
| Point Length (mm) | 1.30mm |
| Number of Flutes | 2 |
| Series | DJ543 |
| Point Angle | 120 Degree |
| Helix Angle | 38 Degree |
| Length/Diameter | Stub |
| Shank Tolerance | h7 |
| Coolant Through | No |
| Coating | TiN |
| Material | HSS EX |
| Hole Tolerance | h8 |
| Application | P,M |
| Cutting Direction | Right |
| Blank Standard | DIN6535-HA |
