Product Specifications
| Manufacturer Part Number | 1291KCN |
| Diameter (Inch) | 32/63" |
| Diameter (Decimal Inch) | 0.5079" |
| Diameter (mm) | 12.90mm |
| Shank Diameter (Inch) | 32/63" |
| Shank Diameter (Decimal Inch) | 0.5079" |
| Shank Diameter (mm) | 12.90mm |
| Flute Length (Inch) | 3-83/85" |
| Flute Length (Decimal Inch) | 3.9764" |
| Flute Length (mm) | 101.00mm |
| Overall Length (Inch) | 6-15/68" |
| Overall Length (Decimal Inch) | 6.2205" |
| Overall Length (mm) | 158.00mm |
| Point Length (Decimal Inch) | 0.1466" |
| Point Length (mm) | 3.72mm |
| Number of Flutes | 2 |
| Series | DJ544 |
| Point Angle | 120 Degree |
| Helix Angle | 38 Degree |
| Length/Diameter | Jobber |
| Shank Tolerance | h7 |
| Coolant Through | No |
| Coating | TiN |
| Material | HSS EX |
| Hole Tolerance | h8 |
| Application | P,M |
| Cutting Direction | Right |
| Blank Standard | DIN6535 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Drill Bit Size (Inch):
32/63"
Drill Bit Size (Decimal Inch):
0.5079"
Drill Bit Size (mm):
12.90mm
Cutting Direction:
Right
Material:
HSS EX
Finish/Coating:
TiN
Coolant Through:
No
interval quantity:
1
