Product Specifications
| Manufacturer Part Number | D1211105 |
| Diameter (Inch) | 1-5/64" |
| Diameter (Decimal Inch) | 1.0781" |
| Diameter (mm) | 27.38mm |
| Flute Length (Inch) | 6-7/8" |
| Flute Length (Decimal Inch) | 6.8750" |
| Flute Length (mm) | 174.63mm |
| Overall Length (Inch) | 12-1/2" |
| Overall Length (Decimal Inch) | 12.5000" |
| Overall Length (mm) | 317.50mm |
| Point Length (Decimal Inch) | 0.3239" |
| Point Length (mm) | 8.23mm |
| Number of Flutes | 2 |
| Morse Taper | 4 |
| Point Angle | 118 Degree |
| Helix Angle | 33 Degree |
| Coolant Through | No |
| Blank Standard | ANSI |
| Coating | Oxide |
| Material | HSS |
| Hole Tolerance | h8 |
| Application | P |
| Cutting Direction | Right |
| Series | D1211 |
