Product Specifications
| Diameter (Decimal Inch) | T7426467H2 |
| Diameter (Decimal Inch) | 0.3690" |
| Diameter (mm) | 9.37mm |
| Overall Length (Decimal Inch) | 2.9400" |
| Overall Length (mm) | 74.68mm |
| Thread Length (Decimal Inch) | 1.2500" |
| Thread Length (mm) | 31.75" |
| Square Length (Decimal Inch) | 1.2500" |
| Square Length (mm) | 31.75" |
| Shank Diameter (Decimal Inch) | 0.3810" |
| Shank Diameter (mm) | 9.68mm |
| Square Size (Decimal Inch) | 0.2860" |
| Square Size (mm) | 7.26mm |
| Drill Size (Decimal Inch) | 0.3228" |
| Drill Size (mm) | 8.20mm |
| Useable Length (Decimal Inch) | 1.2500" |
| Useable Length (mm) | 31.75mm |
| Length/Diameter | 2.0xD |
| Coolant Through | No |
| Tap Type | STFL |
| Number Of Flutes | 4 |
| Size | 5/16 |
| Pitch | 24 TPI |
| Thread Series | UNF |
| Pitch Limit | H2 |
| Chamfer Type | Plug |
| Chamfer Length | 4P-5P |
| Finish | Bright |
| Material | HSS |
| Blank Standard | 322 |
| Product Type | Spiral Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (mm):
9.37mm
Number of Flutes:
4
Chamfer:
Plug
Material:
HSS
Finish/Coating:
Bright
Through Coolant:
No
interval quantity:
1
