3M 7010374610 | 9795 60 yd x 54.000" Width Double Sided Tape

3M double coated tape 9795 stands up under tough conditions, yet provides stability and handles easily during processing. This double coated tape features a thin .5 mil black polyester film carrier coated on both sides with 3M high tack Adhesive 420, excellent for bezel, display and electronic component bonding. A printed 58-lbs. PCK liner adds stability for efficient processing.

3M Double Coated Tape 9795 is a 5.7 mil PET tape designed for application and use in a range of temperatures. This tape features a .5 mil polyester film carrier which delivers excellent handling during processing such as slitting, die-cutting, and laminating. The face side is coated with 2.8 mils and the back side with 2.3 mils of 3M Adhesive 420, which is excellent for applications such as bonding bezels, cover lenses, and electronic components. This adhesive delivers very high impact resistance, initial adhesion, and exceptional temperature resistance.

A 4 mil, 58-lbs. polycoated kraft printed liner adds stability for efficient processing such as die-cutting.

• Bezel bonding
• Cover lens bonding
• Display bonding
• Electronic component bonding
• Touch panel bonding

3M Adhesive 420 is a medium firm acrylic adhesive that provides good adhesion to metals and medium surface energy (MSE) plastics such as polycarbonate, ABS, acrylic, and polyimide. It delivers excellent temperature resistance in tough application environments, with an operating temperature of up to 250°F/121°C and short-term temperature resistance up to 300°F/149°C. It also bonds at temperatures as low as 32°F/0°C and provides impact resistance.

In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in construction, fabrication, arts, and hobbies.

• 0.5 mil PET carrier adds dimensional stability and makes for easier handling during lamination and die-cutting
• 3M Adhesive 420 delivers high impact and temperature resistance
• Designed with 2.8 mil face side adhesive and 2.3 mil adhesive on the back side for a range of applications
• 4.2 mil 58# printed PCK liner adds stability for storage and die-cutting
