Features:
- Heavy core design adds rigidity for cutting difficult to machine materials
- Tight corner radius tangency tolerance for quality recoil grooves
- Specially engineered flute design adds strength and improves chip flow
- Meets MIL-STD 1913
Product Specifications
| Cutting Diameter (Inch) | 0.210" |
| Shank Diameter (Inch) | 0.250" |
| Length of Cut (Inch) | 0.118" |
| Overall Length (Inch) | 1.750" |
| Cut of Direction | Right Hand |
| Flute Type | Spiral |
| Corner Radius (Inch) | 0.010" |
| Helix Angle | 35 Degree |
| Coating | AlTiN |
| Number of Flutes | 3 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Number of Flutes:
3
End Type:
Corner Radius
Corner Radius (Inch):
1/64"
Corner Radius (Decimal Inch):
0.0100"
Corner Radius (mm):
0.25mm
Length of Cut (Inch):
1/8"
Length of Cut (Decimal Inch):
0.1180"
Length of Cut (mm):
3.00mm
Finish/Coating:
TA
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Shank Diameter (mm):
6.35mm
Overall Length (Inch):
1-3/4"
Overall Length (Decimal Inch):
1.7500"
Overall Length (mm):
44.45mm
Cutting Direction:
RHC
