Features:
- 3.5X clamping force of standard hydraulic chucks
- 74% thicker bore walls improve rigidity in heavy material removal applications
- Excellent vibration dampening properties enhances surface finish and extends tool life
Product Specifications
| Taper | BT30 |
| Nose Diameter (mm) | 42mm |
| Body Diameter (mm) | 42mm |
| Overall Diameter (mm) | 31.75mm |
| Projection (mm) | 90mm |
| Nose Length (mm) | 68mm |
| Bore Depth (mm) | 48mm |
| Overall Length (mm) | 138.4mm |
