Features:
- Balanced to 25,000 RPM at G2.5
- Maximum 0.0001" T.I.R. measured from taper to collet pocket
- PowerCOAT Nut increases holding power by 75%
Product Specifications
| Collet Series | ER32 |
| Overall Diameter (mm) | 50mm |
| Shank Size (mm) | 50mm |
| Taper Length (mm) | 47.8mm |
| Overall Length (mm) | 97.8mm |
| Projection (mm) | 50mm |
| Nose Diameter (mm) | 50mm |
| Wrench | 04616 |
| Nut | 46132-L |
| Flats (mm) | 47mm |
| Capacity Range (Inch) | 0.043" - 0.827" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
ISO30
Collet Series:
ER32
Shank Size (mm):
50.00mm
Body Diameter (mm):
50.00mm
Nose Diameter (mm):
50.00mm
Taper Length (mm):
47.80mm
Overall Length (mm):
97.80mm
interval quantity:
1
