Titan USA high performance taps features a spiral point.
Features:
- Best used for through hole tapping applications
- Optimized for steel, steel alloys, stainless steels, and a variety of other steels up to 32 Rc
- Taps are on blanks that meet ANSI specifications
- TiCN coating adds enhanced performance when AlTiN cannot be used
- Premium powdered metal
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT98967 |
| Shank Diameter (Inch) | 0.2550" |
| Length of Cut (Inch) | 0.7500" (3/4) |
| Across Flat (Inch) | 0.1910" |
| End Length (Inch) | 0.3125" (5/16) |
| Overall Length (Inch) | 2.5000" (2-1/2) |
| Thread Size (mm) | M6 X 1.0 |
| Number of Flutes | 3 |
| Limit | D5 |
| Type | SP/PT Plug |
| Coating | TiCN |
| Substrate | Powdered Metal |
| Product Type | Spiral Point Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
