Product Specifications
| Manufacturer Part Number | DB510065 |
| Cutting Diameter (Inch) | 11/43" |
| Cutting Diameter (Decimal Inch) | 0.255" |
| Cutting Diameter (mm) | 6.50mm |
| Shank Diameter (Inch) | 23/73" |
| Shank Diameter (Decimal Inch) | 0.315" |
| Shank Diameter (mm) | 8.00mm |
| Flute Length (Inch) | 2-2/23" |
| Flute Length (Decimal Inch) | 2.087" |
| Flute Length (mm) | 53.00mm |
| Overall Length (Inch) | 3-7/12" |
| Overall Length (Decimal Inch) | 3.583" |
| Overall Length (mm) | 91.00mm |
| Number of Flutes | 2 |
| Point Angle (Degree) | 140 Degree |
| Helix Angle (Degree) | 30 Degree |
| Shank Tolerance | h6 |
| Cutting Direction | Right Hand |
| Coolant Pressure | 20 Bar |
| Coating | TiAlN |
| Material | Carbide |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Cutting Diameter (Inch):
11/43"
Cutting Diameter (Decimal Inch):
0.2550"
Cutting Diameter (mm):
6.50mm
Shank Diameter (Inch):
23/73"
Shank Diameter (Decimal Inch):
0.3150"
Shank Diameter (mm):
8.00mm
Flute Length (Inch):
2-2/23"
Flute Length (Decimal Inch):
2.0870"
Flute Length (mm):
53.00mm
Overall Length (Inch):
3-7/12"
Overall Length (Decimal Inch):
3.5830"
Overall Length (mm):
91.00mm
Hole Tolerance:
m7
Point Angle:
140 Degree
Helix Angle:
30 Degree
Cutting Direction:
Right Hand
Shank Tolerance:
h6
Number of Flutes:
2
Finish/Coating:
TiAlN
Material:
Carbide
interval quantity:
1
