Kyocera Precision Tools TLC10738 | GDG8030N040GS PR1535 0.3150" Cutting width x 1.1811" Insert Length PVD Coated Carbide Grooving Insert

$36.29
Brand:
Kyocera Precision Tools
Insert Style:
GDG
Insert Size:
8030
Material:
Carbide;Cutting Width (Decimal Inch)=0.3150"""
Cutting Width (mm):
8.00mm
Maximum Depth of Cut (Decimal Inch):
0.9843"
Maximum Depth of Cut (mm):
25.00mm
Manufacturer's Grade:
PR1535
Finish/Coating:
PVD
SKU:
23242124
Weight:
0.43 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout

Features:

  • Insert for external grooving
  • Low Cutting Force / 2-edge
  • 2 Cutting edges
  • Stabilized turning operations and long tool life with MEGACOAT NANO coating technology
  • Application: PVD for titanium alloy and precipitation hardened stainless steel

Product Specifications
Tool NumberTLC10738
Max Depth of Cut (Decimal Inch)0.9843"
Max Depth of Cut (mm)25.00mm
Cutting Width (Decimal Inch)0.3150"
Cutting Width (mm)8.00mm
Cutting Width Minimum (Decimal Inch)0.3150"
Cutting Width Minimum (mm)8.00mm
Cutting Width Maximum (Decimal Inch)0.3150"
Cutting Width Maximum (mm)8.00mm
Insert Length (Decimal Inch)1.1811"
Insert Length (mm)30.00mm
Corner Radius (Inch)1/64"
Corner Radius (mm)0.40mm
Thickness (Inch)0.217"
Thickness (mm)5.50mm
ApplicationExternal Grooving
ChipbreakerGS
Coating ProcessPVD
Cutting RangeMedium Roughing
HandNeutral
Insert Holding MethodClamp
Insert GradePR1535
Insert Size8030
MaterialCarbide
Number of Cutting Edges2
Primary Workpiece MaterialHeat-Resistant Alloy (S)
Usage ClassificationLight Interruption
