The 3M Cut-Off Wheel 654BK is a general purpose cut-off wheel for carbide tool manufacturing. With a highly concentrated diamond abrasive mineral, solid construction and a steel core, it is commonly used for trimming tool blanks on carbides, high speed steels and hard metals.
Go-to Wheel for Cutting Tools- A "go-to" wheel, the 3M Cut-Off Wheel 654BK strikes a balance between form retention and cut rate. It is designed to retain form under use. This cut-off wheel features a steel core. The steel core allows the use of smaller wheel flanges and it improves the lateral stability of the cut-off wheel. The resin bond is designed for use with a water-based coolant.
- This wheel conforms to the 1A1R shape and is 6 inches in diameter, 0.35" thick and the arbor hole is 1-1/4".
- This cut-off wheel is an outstanding choice for cutting carbide blanks to length or trimming off the damaged ends of end mills and drill bits prior to re-sharpening.
Features:
- Offers balance between form retention and cut rate
- Performs well on carbides, high speed steels and hard metals
- Resin bond construction with 100 mesh diamond mineral
- Typically used on the cutting end of the tool when re-grinding and the shank end when forming a blank
- Coolant: Water Oil Emulsion
Product Specifications
Manufacturer Part Number | 7010493382 |
Center Hole Diameter (Inch) | 1.25" |
Center Hole Diameter (mm) | 31.75mm |
Overall Diameter (Inch) | 4.0" |
Overall Diameter (mm) | 101.6mm |
Wheel Type | 1F1R |
Product Form | Wheel |
Product Number | 654BK |
Product Type | Cut-off Wheel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
